YBM-12 Type Buried substation

YBM-12 Type Buried substation consists of an underground combination Transformer, a fully insulated fully sealed compact high-voltage cabinet, an outdoor low-pressure cabinet, and a low-pressure protective shell with a light box. It is a complete set of underground Transformer distribution equipment that has been pre-assembled in the factory. According to the needs of users, the lamp box cable branch box and lamp box high voltage measurement can also be added. The ground buried box change is mainly used to replace the traditional civil form substation, European box change, American box change, and realize the new power generation and distribution functions. Power product.

TEL:16515111777

Product details


 YBM-12 Type Buried substation consists of an underground combination Transformer, a fully insulated fully sealed compact high-voltage cabinet, an outdoor low-pressure cabinet, and a low-pressure protective shell with a light box. It is a complete set of underground Transformer distribution equipment that has been pre-assembled in the factory. According to the needs of users, the lamp box cable branch box and lamp box high voltage measurement can also be added. The ground buried box change is mainly used to replace the traditional civil form substation, European box change, American box change, and realize the new power generation and distribution functions. Power product.

  The YBM-12 buried substation is widely used in the construction and transformation of urban small-scale substation, industrial and mining substations and mobile operation substations. It is easy to penetrate into the load center, reduce the power supply radius, improve the end voltage quality, and is especially suitable for urban power grid transformation.


  ◆The buried box can be integrated with the local environment and designed into various landscapes to enhance visual effects;

  ◆The buried box has a small area and the traditional box has a small surface area of more than 70 %.

  ◆Transformers play a certain screen function, effectively reduce noise and electromagnetic radiation;

  ◆The buried box Transformer room is equipped with special channels: ventilation, heat dissipation, Transformer pressure release, and maintenance channels;

  ◆Equipped with automatic drainage and alarm, automatic exhaust cooling system;

  ◆Equipped with mechanical and electrical interlocking devices to ensure five anti-interlocking, to prevent the possibility of physical danger caused by live entry;

  ◆The 10kV high voltage cabinet and the 0.4kV low voltage cabinet are all equipped with separate compartments, and have independent ventilation and heat dissipation channels and ventilation and heat dissipation system.
